Portable Solar Security Tower Guide

This guide includes key elements such as technical details, application cases, and product variants.

Table of Contents

1. Solar Security Tower System Architecture

Energy Module: Uses monocrystalline silicon solar panels (efficiency 21.7%-23.8%). The C600 series is equipped with a 3×420W photovoltaic array, while the S800 series upgrades to an 18×740W array.
Energy Storage Configuration: Options for lead-acid or lithium battery packs. The flagship model Tank T800-9M features a 60kWh lead-acid battery, while the hybrid S800-120 includes a 120kWh lithium battery combined with a diesel generator.
Smart Control: MPPT controller (efficiency 95%), BMS battery management system, and temperature control fan.

C300

2. Solar Security Tower Monitoring Core Technology

Multi-Sensor Fusion: 5MP dual-mode cameras (combination of spherical and gun-type), two-way voice intercom, and PM2.5 monitoring sensors.
AI Recognition Algorithm: Supports face and vehicle recognition (recognition rate ≥98%) and flame detection (response time <2 seconds).
Data Transmission: 4G/WiFi dual channel, supports real-time transmission via RTMP protocol. The C600-9M model has a storage capacity supporting 90 hours of continuous recording.

C500

3. Performance Parameter Comparison

Model	Mast Height	Monitoring Radius	Battery Capacity	Extreme Environment Endurance
C300-3M	3m	150m	720Wh	35 hours
C600-9M	9m	300m	7.2kWh	90 hours
TS C800D-6M	6m	200m	70kWh	80 hours + 24 hours air conditioning power supply

C600

4. Solar Security Tower Deployment Cases

Domestic Projects: Perimeter protection at Daqing Oilfield (deployment of 32 units C600-9M), monitoring at Beijing Daxing Airport construction.
International Projects: Security system at a copper mine in Chile (hybrid version S800-120), inspection of oil pipeline in Canada.

5. Feature Expansion

Environmental Adaptability: IP65 protection rating, -20℃ low-temperature heating module (standard feature of S800 series).
Theft Prevention Design: GPS tracking + electronic fence, automatic alarm for equipment displacement over 50 meters.
Power Expansion: Optional 300W vertical axis wind turbine (starts at wind speed of 1.8m/s) for hybrid wind-solar solutions.

6. Operation and Maintenance Advantages

Save 85% in fuel costs compared to traditional solutions (using C600-9M as an example).
Support remote firmware upgrades with a fault self-diagnosis accuracy rate of over 92%.
Modular design with battery replacement time under 15 minutes.

7. Customization Options

Energy Combinations: Pure solar/ hybrid wind-solar/ mixed solar-diesel.
Monitoring Expansion: Can integrate thermal imaging cameras (detection distance of 500m+).
Mobility Options: Trailer-based (80km/h road speed) or container-style.

It is recommended to insert a model comparison chart in the article along with international certification logos (such as UL, CE) for explanation. In the actual cases section, user feedback data could be added, such as a 76% decrease in theft incidents achieved in the Daqing Oilfield project.
